PCIe |
-
1 PCIe 2.0 x4 (in x8 slot)
|
BIOS Type |
|
BIOS Features |
-
ACPI 5.0
-
USB Keyboard support
-
DMI 2.3
-
SMBIOS 2.7.1
|
Software |
-
SuperDoctor® 5, NMI, SUM, IPMI2.0, Watchdog, IPMI (Intelligent Platform Management Interface) v2.0 with KVM support
|
System Management Software |
-
IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
|
Power Configurations |
-
Power-on mode for AC power recovery, ACPI Power Management, ATX Power connector, +12V DC Power Input, Control of power-on for recovery from AC power loss
|
Voltage |
-
VBAT, System temperature, System level control, Supports system management utility, Memory, Chassis intrusion header, 3 -fan status, +5V standby, +5V, +3.3V, +12V, Memory Voltages
|
LED |
-
UID/Remote UID
-
CPU / System Overheat LED
|
Temperature |
-
CPU thermal trip support
-
Adaptive Thermal Monitor, PECI 3.0
|
FAN |
-
3x 4-pin fan headers (up to 3 fans)
-
Thermal control tachometer fan connectors, System level control, PWM fan speed control, Low noise fan speed control, Fan speed control, 3 fans with tachometer monitoring, Pulse Width Modulated (PWM) fan connectors, Overheat LED indication, Support 3-pin fans (w/o speed control)
|
Other Features |
-
WOL, UID, System level control, RoHS, CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss, Chassis intrusion header, Chassis intrusion detection, ATX Power connector, ACPI power management, 12V DC or ATX Power Source, Intel® QuickAssist Technology, 4-pin 12v DC power connector
|
Operating Temperature Range |
-
0°C - 60°C (32°F - 140°F)
|
Non-Operating Temperature Range |
-
-40°C - 70°C (-40°F - 158°F)
|
Operating Relative Humidity Range |
-
10% - 85% (non-condensing)
|
Non Operating Relative Humidity Range |
-
10% - 95% (non-condensing)
|
|
