X14/H14 Hyper with PCIe 5.0
Flagship Rackmount Servers for a New Generation of Performance and Efficiency
- CPU: Intel® Xeon® 6700/6500 series processors or AMD EPYC™ 9005/9004 series processors
- Memory: Up to 32 DIMMs, 9TB DDR5
- Drives: Up to 12 hot-swap 2.5″ NVMe/SAS/SATA
- PCIe: Up to 3 PCIe 5.0 x16 slots + 1 PCIe 5.0 AIOM slot
X14 DP CloudDC with Intel® Xeon® 6
OCP DC-MHS modular design for scale-out data centers
- CPU: Intel® Xeon® 6700/6500 series processors
- Memory: Up to 32 DIMMs, 2TB DDR5
- Drives: Up to 12 2.5″ NVMe/SAS/SATA
- PCIe: Up to 3 PCIe 5.0 x16 slots + 2 PCIe 5.0 AIOM slots + 1 DC-SCM
N14 Systems with NVIDIA Grace™ CPU Superchip
High Density Configurations Based on the NVIDIA MGX Architecture
- CPU: Dual NVIDIA Grace™ CPU Superchip
- Memory: Up to 960GB onboard memory
- Drives: Up to 2 hot-swap E1.S NVMe
- PCIe: Up to 2 PCIe 5.0 x16 slots
X13/H13 Hyper with PCIe 5.0
Next-Generation Performance with Maximum Flexibility for Enterprise Applications
- CPU: 5th/4th Gen Intel® Xeon® Scalable Processors or AMD EPYC™ 9004 Series Processors
- Memory: Up to 32 DIMMs, 8TB DDR5, support for Intel® Optane® Persistent Memory
- Drives: Up to 12 hot-swap 2.5” NVMe/SATA
- PCIe: Up to 3 PCIe 5.0 x16 slots
N15 Systems with NVIDIA Vera CPU
High Density Configurations Based on the NVIDIA MGX Architecture
- CPU: Dual NVIDIA Vera CPU
- Memory: Up to 1.5TB onboard memory
- Drives: Up to 8 hot-swap E1.S NVMe
- PCIe: Up to 4 PCIe 6.0 x16 slots
X13 DP CloudDC with PCIe 5.0
Next-Generation All-in-One Servers Providing High Storage and Expansion Capacity and Flexible I/O Options for Cloud Scale Data Centers
- CPU: 5th/4th Gen Intel® Xeon® Scalable Processors
- Memory: Up to 16 DIMMs, 4TB DDR5, support for Intel® Optane® Persistent Memory
- Drives: Up to 10x 2.5” NVMe/SAS/SATA
- PCIe: Up to 2 PCIe 5.0 x16 slots
X12/H12 Hyper and Ultra with PCIe 4.0
Ultimate Performance and Configurability for Enterprise Applications
- CPU: 3rd Gen Intel® Xeon® Scalable Processors or AMD EPYC™ 7003/7002 Series Processors
- Memory: Up to 32 DIMMs, 8TB DRAM or 12TB Intel® Optane® Persistent Memory
- Drives: Up to 12 Hot-swap 2.5" NVMe/SATA/SAS
- PCIe: Up to 4 PCIe 4.0 x16 slots
X12 CloudDC with PCIe 4.0
High-performance Storage with Flexible I/O Options for Custom Applications
- CPU: 3rd Gen Intel® Xeon® Scalable Processors
- Memory: Up to 16 DIMMs, 4TB DRAM or 6TB Intel® Optane® Persistent Memory
- Drives: Up to 10 hot-swap 2.5" NVMe
- PCIe: 2 PCIe 4.0 x16 (FHHL) slots
