SC732I-R600B | Mid-Tower | Chassis | Products | Supermicro

Key Features

90° Rotatable HDD Cage
Kensington Lock Security
Front I/O Ports: 2x USB 3.0
1x Optional Front 12cm (1850 RPM) PWM Fan
Mid-Tower Chassis Supports Micro-ATX Motherboard, Sizes E-ATX/ATX/Micro ATX
600W Redundant Power supply
1x Rear 12cm (1850 RPM) PWM Fan
2x 5.25" External HDD Drive Bays & 4x 3.5" Internal HDD Drive Bays

Specifications

Product SKUs
SuperChassis 732I-R600B

Form Factor
Mid-Tower chassis support for motherboard size ATX 12" x 10", Micro ATX 9.6" x 9.6", E. ATX 12" x 13"

Processor Support
Dual and Single Intel® and AMD processors

Dimensions
Height	16.7" (424 mm)
Width	7.6" (193 mm)
Depth	20.68" (525 mm)
Gross Weight	30 lbs (13.61 kg)
Net Weight	28 lbs (12.7 kg)
Packaging (W x H x L)	21.38" (543 mm) x 11.97" (304 mm) x 25.28" (642 mm)
Available Color	Black

Expansion Slots
7x Full-height, Full-length expansion slot(s)

Drive Bays
Optional 4x 2.5" fixed drive bay 4x 3.5" fixed drive bay

Peripheral Drives
2x standard 5.25" drive bay 1x 3.5" internal fixed drive bay 1x 90 degree rotatable drive cage

Front Panel
Button	Power On/Off button
LED	Power status LED HDD activity LED 1 Network activity LEDs System Overheat LED
Port	2x USB 3.0 Port(s)

Systems Cooling
Fans	Optional 1x 12cm (front) cooling fan 1x 12cm rear exhaust fan(s)

Operating Environment (System)
Operating Temperature Range	5°C - 35°C (41°F - 95°F)
Non-Operating Temperature Range	-40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range	8% - 90% (non-condensing)
Non Operating Relative Humidity Range	5% - 95% (non-condensing)

Power Supply
600W PS2 Multi-output Redundant Power Supply
Total Output Power and Input	600W with Input 100 - 240Vac
AC Input Frequency	50-60Hz
Dimensions (L x W x H)	190 x 150 x 84 mm
Output Type	24pin ATX
-12V	Max: 0.5A / Min: 0A
+12V	Max: 49A / Min: 1A
+5V	Max: 20A / Min: 0A
+3.3V	Max: 20A / Min: 0A
+5Vsb	Max: 3A / Min: 0A
Certification	N/A

Regulatory (Power Supply)
Power Supply Safety / EMC	BSMI CCC CE/EMC FCC class B TUV/CB UL/CUL

Resources

Chassis Manual

Components

Standard Parts List
	Part Number	Qty	Description
Bracket	MCP-250-73201-0N	1	SC732 PS2 Power Supply Bracket
Cable(s)	CBL-0071L	1	ROUND 16 TO 16 PIN RIBBON FP CABLE 30"L, LF
Cable(s)	CBL-0084L	1	16PIN FRONT CTRL SPLIT CONVECTOR 6",PB FREE
Cable(s)	CBL-CUSB-1007	1	20p,F to 2x USB 3.0 type A,F,70CM,26/30AWG,RoHS
Part(s)	MCP-120-00116-0N	7	Blank FH L-bracket with 4x4 vent holes
Part(s)	MCP-230-73201-0N	1	SC732i USB2.0 Module Assembly
Fan(s)	FAN-0124L4	1	12 CM x12 CM fan
Front Bezel	MCP-210-73201-0B	1	Black SC732i Front IO Dummy Cover
Front Panel	MCP-280-73101-0B	1	Black SC731i Plastic Front Control Panel Assembly
Drive Tray(s)	MCP-220-73101-0B	4	SC731 Tool-less Internal 3.5inch HDD Tray
Power Supply & Accessory	PWS-603R-PQ	1	600W PS2 Redundant Power supply,RoHS

Optional Parts

	Part Number	Qty	Description
2.5" HDD Bracket	MCP-220-73201-0N •		HDD Cage (4x Internal 2.5" fixed HDD bays)
Fan Kit	FAN-0124L4 •		12 CM x12 CM fan
