 | | PCI-E | - 1 PCI-E 2.0 x4 (in x8 slot)
-
| | | | | BIOS Type | | | BIOS Features | - ACPI 5.0
- DMI 2.3
- SMBIOS 2.7.1
- Plug and Play (PnP)
| | | | | Software | - IPMI (Intelligent Platform Management Interface) v2.0 with KVM support, IPMI2.0, NMI, SUM, SuperDoctor® 5, Watchdog
| | System Management Software | - IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
| | Power Configurations | | | | | | Voltage | - +1.8V, +12V, +3.3V, +5V, +5V standby, Chassis intrusion header, Memory, Memory Voltages, Supports system management utility, System level control, System temperature
| | FAN | - 3x 4-pin fan headers (up to 3 fans), Fan speed control, Low noise fan speed control, Overheat LED indication, PWM fan speed control, System level control, Thermal control tachometer fan connectors
| | Temperature | | | LED | - CPU / System Overheat LED, UID/Remote UID
| | Other Features | - 12V DC or ATX Power Source, 4-pin 12v DC power connector, ACPI power management, ATX Power connector, Chassis intrusion detection, Chassis intrusion header, Control of power-on for recovery from AC power loss, CPU thermal trip support for processor protection, Intel® QuickAssist Technology , RoHS, System level control, UID, WOL
| | |  | | Operating Temperature Range | - 0°C ~ 60°C (32°F ~ 140°F)
| | Non-Operating Temperature Range | - -40°C - 85°C (-40°F - 185°F)
| | Operating Relative Humidity Range | - 10% ~ 85% (non-condensing)
| | Non-Operating Relative Humidity Range | - 5% - 95% (non-condensing)
| |
