 | | PCI-E | - 1 PCI-E 3.0 x8,
- 2 PCI-E 3.0 x16,
- 1 PCI-E 3.0 x8 for Add-On-Module (AOM)
- 4 Port NVMe PCI-E 3.0 x4 via OCuLink
| | | | | BIOS Type | - 128Mb SPI Flash EEPROM with AMI BIOS
| | BIOS Features | - Plug and Play (PnP)
- PCI 2.3
- ACPI 1.0 / 2.0 / 3.0 / 4.0
- USB Keyboard support
- SMBIOS 2.7.1
- UEFI 2.3.1
| | | | | Software | - Intel® Node Manager, IPMI2.0, KVM with dedicated LAN, NMI, SPM, SUM, SuperDoctor® 5, Watchdog
| | Power Configurations | - ACPI Power Management
- Power-on mode for AC power recovery
| | | | | Voltage | - +1.8V, +12V, +3.3V, +5V, +5V standby, 3.3V standby, 6 Phase-switching voltage regulator, Memory Voltages, Monitors for CPU Cores, VBAT
| | FAN | - 4x 4-pin fan headers (up to 4 fans), 4 fans with tachometer monitoring, Pulse Width Modulated (PWM) fan connectors, Status monitoring for speed control
| | Temperature | - Monitoring for CPU and chassis environment, CPU thermal trip support, Thermal Control for 8 Fan Connectors, Thermal Monitor 2 (TM2) support, PECI
| | LED | - CPU / System Overheat LED, Suspend static indicator LED, UID/Remote UID
| | Other Features | - Chassis intrusion detection, Chassis intrusion header, RoHS, SDDC
| | |  | | Operating Temperature Range | - 10°C - 35°C (50°F - 95°F)
| | Non-Operating Temperature Range | - -40°C - 70°C (-40°F - 158°F)
| | Operating Relative Humidity Range | - 8% - 90% (non-condensing)
| | Non-Operating Relative Humidity Range | - 5% - 95% (non-condensing)
| |
SC226SN-R1K62
