Part Number |
Qty |
Description |
|
1U Cable Management Arm
|
MCP-290-00165-0N |
1 |
1U Supermicro Cable Management Arm 3rd Gen |
|
Add-on card for M.2 support
|
AOC-SLG4-2H8M2-O |
- |
2x Hybrid Gen 4 NVMe/SATA M.2 RAID 0/1 Carrier, Standard |
|
CacheVaults
|
BTR-CV3108-1U1 |
- |
CacheVault for Broadcom 3108 with Supercap mounting in 1U 40x56 fan tray |
| BTR-CVPM05 + BKT-BBU-BRACKET-05 |
- |
CacheVault for Broadcom 3908/3916 with Supercap |
|
Drive Tray
|
MCP-220-00178-0B |
1 ~ 12 |
2.5 thin profile drive tray, Orange tab (for hotswap NVMe drive), for SC119UH |
|
Global Services & Support
|
OSNBD3/2/1 |
- |
3/2/1-year onsite NBD service |
| OS4HR3/2/1 |
- |
3/2/1-year onsite 24x7x4 service |
|
Intel® VROC RAID Key Options
|
AOC-VROCINTMOD |
1 |
Intel VROC, RAID 0, 1, 5, 10 (Intel SSD Only) |
| AOC-VROCPREMOD |
1 |
Intel VROC Premium, RAID 0, 1, 5, 10 |
| AOC-VROCSTNMOD |
1 |
Intel VROC Standard, RAID 0, 1, 10 |
|
Internal Drive Tray for Two 2.5" Drives
|
CBL-PWEX-0650CBL-0080L |
12 |
Power Cable for Two internal 2.5" drives |
| MCP-120-82916-0N |
1 |
2.5” Internal Drive Bay (Slim DVD Tray) |
| CBL-0484L OrCBL-SAST-0654 OrCBL-SAST-0948 |
211 |
SATA3 S-S CableminiSAS(iPass) to 4 SATA CableminiSAS HD to 4 SATA Cable |
|
Network Card(s)
|
AOC Compatibility Matrix |
- |
Standard Networking AOC Matrix |
|
NVMe Support Cable Kit
|
CBL-KIT-120U-TNR-12-1 |
1 |
12 NVMe Cables Kit for X12 Ultra SYS-120U-TNR |
|
Optional Storage Controller Card + Cable(s)
|
AOC-S3108L-H8iR-16DD + 1x CBL-SAST-1260-100 |
- |
Standard LP, 8 internal ports (12Gb/s) Gen-3; RAID 0, 1, 5, 6, 10, 50, 60 |
| AOC-S3008L-L8i + 1x CBL-SAST-1260-100 |
- |
Standard LP, 8 internal ports (12Gb/s) Gen-3; RAID 0,1,1E |
| AOC-S3008L-L8E+-O + 1x CBL-SAST-1260-100 |
- |
Standard LP, 8 internal ports (12Gb/s) Gen-3; HBA + I2C |
| AOC-S3008L-L8E + 1x CBL-SAST-1260-100 |
- |
Standard LP, 8 internal ports (12Gb/s) Gen-3; HBA |
| AOC-S3808L-L8iT-O + 1x CBL-SAST-1264F-100 |
- |
Standard LP, 8 internal ports (12Gb/s) Gen-4; HBA |
| AOC-S3816L-L16iT-O + 1x CBL-SAST-1264F-100, 1x CBL-SAST-1265F-100 |
- |
Standard LP, 16 internal ports (12Gb/s) Gen-4; HBA |
| AOC-S3908L-H8iR-16DD-O + 1x CBL-SAST-1271F-100 |
- |
Standard LP, 8 internal ports (12Gb/s) Gen-4; RAID 0, 1, 5, 6, 10, 50, 60 |
| AOC-S3916L-H16iR-32DD-O + 1x CBL-SAST-1265F-100, 1x CBL-SAST-1271F-100 |
- |
Standard LP, 16 internal ports (12Gb/s) Gen-4; RAID 0, 1, 5, 6, 10, 50, 60 |
|
Power Supply
|
PWS-1K62A-1R |
2 |
1U 1600W, Titanium Level, Redundancy, AC Input: 90 - 264 VAC/47-63Hz |
| PWS-1K30D-1R |
2 |
1U 1300W, Redundancy, DC Input: -48Vdc |
| PWS-2K08A-1R |
2 |
1U 2000W, Titanium Level, Redundancy, AC Input: 90-264VAC/47-63Hz, and wide DC input 180Vdc~300Vdc |
|
Software
|
SFT-DCMS-Single |
1 |
DataCenter Management Package (per node license) |
|
Trusted Platform Module Options
|
AOM-TPM-9671V-O |
1 |
SPI Capable Vertical TPM 1.2 Module |
| AOM-TPM-9670V-O |
1 |
SPI TPM 2.0 using SLB9670 |
| AOM-TPM-9670V-S-FIPS-P |
1 |
AOM-TPM-9670V-S-FIPS TPM 2.0 support TAA and FIPS,RoHS |
|
Ultra Riser Card Options + Rear Window
|
AOC-URG4N4-m2TS + MCP-240-81915-0N |
1 |
1U Ultra Riser 2-port 25GbE SFP28, based on Mellanox CX-6 LX, with 1 PCIe 4.0 x16 (internal), and 4 NVMe ports (2x SlimSAS x8),RoHS |
| AOC-URG4N4-I2XT-O + MCP-240-81909-0N |
1 |
1U Ultra Riser with 2-port 10GBase-T RJ45, based on Intel Carlsville X710-AT2, with 1 PCIe 4.0 x16 (internal), and 4 NVMe ports (2x SlimSAS x8),RoHS |
| AOC-URG4N4-O |
1 |
1U Ultra Riser without NIC, with 1 PCIe 4.0 x16 (internal), and 4 NVMe ports (2x SlimSAS x8).,RoHS |
| AOC-URG4N4-B2XT-O + MCP-240-81909-0N |
1 |
1U Ultra Riser 2-port 10GbE RJ45, Broadcom BCM57416, with 1 PCIe 4.0 x16 (internal), and 4 NVMe ports (2x SlimSAS x8),RoHS |
| AOC-URG4N4-I4XTS-O + MCP-240-81911-0N |
1 |
1U Ultra Riser with 2-port 10GBase-T RJ45 & 2-port 10G SFP+, based on Intel Carlsville X710-TM4, with 1 PCIe 4.0 x16 (internal), and 4 NVMe ports (2x SlimSAS x8),RoHS |
