X14SDW-36C-SP9F (Nur für SuperServer)

X14SDW-36C-SP9F
Proprietary Embedded Motherboard
Intel® Xeon® 6 SoC

Key Features


  1. System on Chip
  2. Intel® Xeon® 6 SoC 6553P-B, CPU TDP 235W, Intel Quick Assist Technology, Intel Media Accelerator
  3. Up to 512GB ECC RDIMM DDR5-6400MT/s in 4 DIMM slots
  4. 2 PCIe 5.0 x16 via Riser slot
  5. 1 PCIe 4.0 x8 via MCIO connector
  6. 8 25GbE SFP28 with Intel SoC, 1 1GbE RJ-45 with Intel® Ethernet Controller i210IT
  7. 12V DC or ATX Power Input
  8. Onboard TPM2.0
...
...
Specifications Resources
Specifications
Product SKUs
MBD-X14SDW-36C-SP9F
Physical Stats
Form Factor
  • Proprietary
Dimension
  • 8" x 13" (20.32cm x 33.02cm)
Processor
CPU
  • Intel® Xeon® 6 SoC
Core Count
  • Up to 36C
Note
  • Supports up to 235W TDP CPUs
System Memory
Memory
  • Slot Count: 4 DIMM Slots
  • Max Memory (1DPC): Up to 512GB 6400MT/s ECC DDR5 RDIMM
DIMM Sizes
  • RDIMM:16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB
Memory Voltage
  • 1.1V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset
  • System on Chip
IPMI
  • ASPEED AST2600 BMC
Network Controller
  • Single LAN with 1GbE with Intel® I210
  • Octal LAN with 25G SFP28 LAN via SoC
Input / Output
USB
  • 2 Type-A port(s) (Rear)
Video
  • 1 Aspeed AST2600 BMC port(s)
  • 1 Mini DP port(s)
Serial
  • 1 COM port(s) (header)
TPM
  • 1 TPM Header & Chip both
Expansion Slots
PCI-Express (PCIe) Configuration
  • 1 PCIe 4.0 x8 via MCIO Connector slot
  • 2 PCIe 5.0 x16 Right Riser slots
M2
  • 1 M.2 PCIe 4.0 x2 NVMe slot (M-key 2280(default))
System BIOS
BIOS Type
  • AMI 64MB UEFI
BIOS Features
  • ACPI 6.5
  • UEFI 2.9
  • Plug and Play (PnP)
  • PCI FW 3.3
  • SMBIOS 3.7
Security
Hardware
  • Trusted Platform Module (TPM) 2.0
PC Health Monitoring
Voltage
  • +12V,+3.3V,+5V,+5V standby,Monitors CPU voltages,Supports system management utility,System level control,VBAT
LED
  • CPU/system overheat LED
  • UID/remote UID LED
Temperature
  • CPU thermal trip support
  • Monitoring for CPU and chassis environment
  • PECI
  • Thermal monitor 2 (TM2) support
FAN
  • 6x 4-pin fan headers (up to 6 fans)
  • Fan speed control
Other Features
  • ACPI power management
  • Control of power-on for recovery from AC power loss
  • UID
  • WOL
