| PCIe |
- 2 PCIe 3.0 x16 (Low Profile),
- 4 PCIe 3.0 x16
|
| M.2 |
- M.2 Interface: 2 PCIe 3.0 x2
- Form Factor: 2260/2280/22110
- Key: M-Key
- *2 SATA Hybrid ports, RAID 0 & 1
|
| Software |
- SuperDoctor® 5, NMI, SUM, KVM with dedicated LAN, SPM, Intel® Node Manager, SSM, IPMI2.0, Watchdog, IPMI (Intelligent Platform Management Interface) v2.0 with KVM support
|
| System Management Software |
- IPMI (Intelligent Platform Management Interface) v1.5 / 2.0 with KVM support
|
| Power Configurations |
|
| Voltage |
- VBAT, Monitors CPU voltages, Chipset voltage, +5V standby, +5V, +3.3V, +12V, +1.8V, Memory Voltages
|
| LED |
- UID/remote UID LED
- CPU/system overheat LED
|
| Temperature |
- Monitoring for CPU and chassis environment
|
| FAN |
- 8x 4-pin fan headers (up to 8 fans)
- System level control
- PWM fan speed control
- Status monitoring for speed control
- 8 fans with tachometer monitoring
|
| Other Features |
- WOL, UID, System level control, RoHS, Node manager support, CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss, Chassis intrusion header, Chassis intrusion detection, RoHS, Halogen Free, Intel® QuickAssist Technology, Innovation Engine
|
| Operating Temperature Range |
- 10°C - 35°C (50°F - 95°F)
|
| Non-Operating Temperature Range |
- -30°C - 60°C (-22°F - 140°F)
|
| Operating Relative Humidity Range |
- 8% - 90% (non-condensing)
|
| Non Operating Relative Humidity Range |
- 5% - 95% (non-condensing)
|
|
