Supermicro WekaIO 分佈式儲存解決方案

難以想像的共享和並行檔案系統,可最大限度地提高儲存性能,滿足最極端的需求!

解決方案概述

隨著資料風暴如雨點般湧向當今的企業系統,淹沒了容量,並挑戰 IT 基礎架構將資料分發到需要它的應用程序,為資料匱乏的應用程序提供資料並獲取最大價值變得越來越具有挑戰性。

Supermicro 和 Weka 共同提供利用 NVMe 閃存的高性能、超低延遲共享和並行檔案儲存解決方案。捆綁解決方案在Supermicro選定的 NVMe 系統上運行,支持最高性能的處理器、記憶體、儲存和網路。它專為 NVMe 快閃記憶體和雲端原生設計和優化,可加速當今的資料中心並推動突破性創新。

無論規模如何,您都可以準備好以前所未有的速度和性能解開資料中心的全部功能。

解決方案優勢

WekaFS 將整個資料湖統一到一個共享的全局命名空間中,您可以在其中輕鬆地從一個目錄訪問和管理數萬億個檔案。它可以立即適應任何新的工作負載,無需調整,也無需專業知識。 Weka存在於您的資料所在的任何位置,無論是在本地、公共雲中還是在兩者之間共享。

WekaIO Solution Diagram 1
WekaIO Solution Diagram 2

專為雲端構建

在本地、雲端中和平台之間無縫運行

共享儲存架構

享受從任何應用程序到單個資料命名空間的共享訪問

針對 NVMe優化

實現盡可能低的延遲以及最高的頻寬和 IOPS 性能

多協議就緒

支援 Linux、視窗和本機 POSIX 存取資料

内置耐用性

使用分佈式資料保護和即時備份到 S3 雲以實現快速恢復

高級安全性

通過整合的加密、密鑰管理和訪問控制確保資料完全安全

使用案例

人工智能和機器學習

生命科學,包括基因組學和 Cryo-EM

金融交易,包括 回溯測試、時間序列分析和風險管理

工程 DevOps

電子設計與自動化

媒體渲染和視覺效果 (VFX)

高性能计算 (HPC)

高性能資料分析,例如 Cassandra, SAS 和 Splunk

產品簡介

Supermicro-NVMe 參考架構實現了下一代智能基礎架構平台,旨在為應用程序提供您期望從本地儲存中獲得的所有原始性能,以及傳統基於儲存區域網路的解決方案通常具有的所有靈活性、可管理性和可擴展性。該參考架構利用最新的 NVMe 和PCIe 標準,使用低延遲、高頻寬網路,以靈活的方式將計算和儲存連接在一起,幾乎可滿足任何應用的架構要求。在以儲存為中心、以計算為中心或混合儲存和計算配置中部署此 RA,並根據需要將其與現有資料中心應用伺服器整合.

Scale Out diagram

Reference Architecture - AMD & Intel PCI-E 5.0 Systems

System GenerationH13 (AMD PCIe Gen5)X13 (Intel PCIe Gen5)
ImageAS -WK1032C-GEN5ASG-WK1032C-NE3SYS-221BT-WK4NSSG-WK1248C-NE3
Form Factor8U8U4U8U
Supermicro Weka Bundle SKU**** 8x AS -WK1032C-GEN5 (1U 1N)
or 8x AS -WK1048C-GEN5 (1U 1N)
*** 8x ASG-WK1032C-NE3 (1U 1N)
or 8x ASG-WK1048C-NE3 (1U 1N)
*** 2x SYS-221BT-WK4N (2U 4N)*** 8x SSG-WK1248C-NE3 (1U 1N)
CPU per node1x AMD Genoa 32C
or 1x AMD Genoa 48C
1x AMD Genoa 32C
or 1x AMD Genoa 48C
2x Intel SPR 16C2x Intel SPR 24C
Storage Media NVMe80x (up to 10x NVMe per node) 2.5"128x (up to 16x NVMe per node) E3.S48x (up to 6x NVMe per node) 2.5"128x (up to 16x NVMe per node) E3.S
Network**16x Single -port Mellanox CX-7 400G VPI16x Single -port Mellanox CX-7 400G VPI16x Single -port Mellanox CX-7 400G VPI16x Single -port Mellanox CX-7 400G VPI
Weka License1yr, 3yr, 5yr options1yr, 3yr, 5yr options1yr, 3yr, 5yr options1yr, 3yr, 5yr options

*Supermicro bundle SKU already includes CPU, Memory, boot devices, MGMT NIC, Supermicro Management Software Suite (DCMS) and OS installation service required for Weka storage solution.

**Network: option w/ 200G is available.

***A Weka cluster requires a minimum of 8x nodes

參考架構 – 採用 AMD 和 Intel PCI-E 4.0 系統

System GenerationH12 (AMD with PCI-E 4.0)X12 (Intel with PCI-E 4.0)
Image8x AS -1114S-WN10RT8x AS -2114S-WN24RT2x SYS-220BT-HNTR3x SYS-220BT-DNTR
Supermicro SKU8x AS -1114S-WN10RT
(1U 1-Node)
8x AS -2114S-WN24RT
(2U 1-Node)
2x SYS-220BT-HNTR
(2U 4-Node)
4x SYS-220BT-DNTR
(2U 2-Node)
Form Factor8U16U4U8U
Usable Capacity363TB726TB218TB436TB
Storage Media NVMe*80x(10x 7.68TB/node)
Gen4 NVMe
160x (20x 7.68TB/node)
Gen4 NVMe
48x (6x 7.68TB/node)
Gen4 NVMe
96x (12x 7.68TB/node)
Gen4 NVMe
CPU8x AMD EPYC™ 7402P Processors**8x AMD EPYC™ 7402P Processors**16x Intel® Xeon® Silver 4314 Processors16x Intel® Xeon® Silver 4314 Processors
Memory2048GB2048GB2048GB2048GB
Network16x single-port
Mellanox CX-6 200G VPI
16x single-port
Mellanox CX-6 200G VPI
16x single-port
Mellanox CX-6 200G VPI
16x single-port
Mellanox CX-6 200G VPI
IOPS***10.2M
(1.275M per node)
8.4M
(1.05M per node)
8.5M
(1.06M per node)
11.28M
(1.41M per node)
Bandwidth***235GB/s
(29.4GB/s per node)
280GB/s
(35GB/s per node)
202GB/s
(25GB/s per node)
286GB/s
(35.8GB/s per node)
I/O Latency< 200μs< 200μs< 200μs< 200μs
SW Subscription1yr, 3yrs, 5yrs1yr, 3yrs, 5yrs1yr, 3yrs, 5yrs1yr, 3yrs, 5yrs

* To request drives of a different capacity, please contact weka-pm@supermicro.com or _nl_weka-pm@supermicro.com (for EMEA region) or APAC_weka-pm@supermicro.com (for APAC region).
** 3rd Gen AMD EPYC™ 7003 Processors are available.
*** Estimated; number varies based on actual components used.

Reference Architecture – AMD and Intel Delta GPU Systems with GPUDirect storage enable

Image1x AS -4124GO-NART (AMD Delta GPU System)1x SYS-420GP-TNAR (Intel Delta GPU System)
Supermicro SKU1x AS -4124GO-NART
(AMD Delta GPU System)
1x SYS-420GP-TNAR
(Intel Delta GPU System)
CPU2x AMD EPYC 7H12 CPU 64C @2.6GHz2x Intel Xeon 8380 CPU 40C @3.4GHz
GPU8x NVIDIA A100-SXM4-80GB8x NVIDIA A100-SXM4-80GB
Memory2TB DDR4-32002TB DDR4-3200
OSOS: Ubuntu 20.04.3
OS Disk: 7.68TB NVMe
OS: Ubuntu 20.04.3
OS Disk: 7.68TB NVMe
NVMeOptionalOptional
GDS Enable SKUPRD-STORAGE, SFT-LT-15S01000300PRD-STORAGE, SFT-LT-15S01000300

*To enable GPUDirect for the GPU system, please add 1x PRD-STORAGE & SFT-LT-15S01000300 per system
Hassle-free GPU Framework Installation utility (SFT-LT-15S01000300) can also be sold alone with other GPU systems. Please contact weka-pm@supermicro.com for details.

Weka 參考體系結構認證的伺服器

AS -1115CS-TNR

AS -1114S-WN10RT

1U 1-Node WIO

AMD with PCI-E 4.0

AS -1114S-WN10RT

  • Single AMD EPYC™ 7003/7002 Series Processor
  • 16 DIMMs; up to 4TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
  • 2 PCI-E 4.0 x16 (FHHL) slots, 1 PCI-E 4.0 x16 (LP) slot
  • 10 Hot-swap NVMe/SATA3 hybrid drive bays
  • 750W Redundant Platinum Level Power Supplies
ASG-1115S-NE316R

AS -1114S-WN10RT

1U 1-Node WIO

AMD with PCI-E 4.0

AS -1114S-WN10RT

  • Single AMD EPYC™ 7003/7002 Series Processor
  • 16 DIMMs; up to 4TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
  • 2 PCI-E 4.0 x16 (FHHL) slots, 1 PCI-E 4.0 x16 (LP) slot
  • 10 Hot-swap NVMe/SATA3 hybrid drive bays
  • 750W Redundant Platinum Level Power Supplies
SYS-221BT-HNR

AS -1114S-WN10RT

1U 1-Node WIO

AMD with PCI-E 4.0

AS -1114S-WN10RT

  • Single AMD EPYC™ 7003/7002 Series Processor
  • 16 DIMMs; up to 4TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
  • 2 PCI-E 4.0 x16 (FHHL) slots, 1 PCI-E 4.0 x16 (LP) slot
  • 10 Hot-swap NVMe/SATA3 hybrid drive bays
  • 750W Redundant Platinum Level Power Supplies
SSG-121E-NE316R

AS -1114S-WN10RT

1U 1-Node WIO

AMD with PCI-E 4.0

AS -1114S-WN10RT

  • Single AMD EPYC™ 7003/7002 Series Processor
  • 16 DIMMs; up to 4TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
  • 2 PCI-E 4.0 x16 (FHHL) slots, 1 PCI-E 4.0 x16 (LP) slot
  • 10 Hot-swap NVMe/SATA3 hybrid drive bays
  • 750W Redundant Platinum Level Power Supplies
AS -1114S-WN10RT

AS -1114S-WN10RT

1U 1-Node WIO

AMD with PCI-E 4.0

AS -1114S-WN10RT

  • Single AMD EPYC™ 7003/7002 Series Processor
  • 16 DIMMs; up to 4TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
  • 2 PCI-E 4.0 x16 (FHHL) slots, 1 PCI-E 4.0 x16 (LP) slot
  • 10 Hot-swap NVMe/SATA3 hybrid drive bays
  • 750W Redundant Platinum Level Power Supplies
AS -2114S-WN24RT

AS -2114S-WN24RT

2U 1-Node WIO

AMD with PCI-E 4.0

AS -2114S-WN24RT

  • Single AMD EPYC™ 7003/7002 Series Processor
  • 16 DIMMs; up to 4TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
  • 1 PCI-E 4.0 x16 (FH/HL) slot
  • 24 Hot-swap NVMe/SATA3 drive bays
  • 1200W Redundant Titanium Level Power Supplies
AS -F1114S-RNTR

AS -F1114S-RNTR

4U 8-Node FatTwin®

AMD with PCI-E 4.0

AS -F1114S-RNTR

  • 8 hot-pluggable nodes in 4U; each node supports:
  • Single AMD EPYC™ 7003/7002 Series Processor
  • 8 DIMMs; up to 2TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
  • 1 PCI-E 4.0 x16 (LP Riser) slot, 1 PCI-E 3.0 x16 (for AIOM)
  • 6 Hot-swap 2.5" NVMe/SATA3 drive bays: 2 NVMe/SATA3 + 4 SATA3 (optional NVMe)
  • 2200W Redundant Titanium Level Power Supplies
SYS-220BT-HNTR

SYS-220BT-HNTR

2U 4-Node BigTwin®

Intel with PCI-E 4.0

SYS-220BT-HNTR

  • 4 hot-pluggable nodes in 2U; each node supports:
  • Dual 3rd Gen Intel® Xeon® Scalable processors
  • 20 DIMMs; Up to 6TB DDR4-3200: Intel® Optane™ Persistent Memory 200 Series; Up to 4TB ECC DDR4-3200: RDIMM
  • 2 PCI-E 4.0 x16 (LP) slots
  • 6 Hot-swap 2.5" NVMe/SATA drive bays
  • 2600W Redundant Titanium Level Power Supplies
SYS-220BT-DNTR

SYS-220BT-DNTR

2U 2-Node BigTwin®

Intel with PCI-E 4.0

SYS-220BT-DNTR

  • 2 hot-pluggable nodes in 2U; each node supports:
  • Dual 3rd Gen Intel® Xeon® Scalable processors
  • 20 DIMMs; Up to 6TB DDR4-3200: Intel® Optane™ Persistent Memory 200 Series; Up to 4TB ECC DDR4-3200: RDIMM
  • 1 PCI-E 4.0 x16 (LP) slot, 2 PCI-E 4.0 x8 slots
  • 12 Hot-swap 2.5" NVMe/SATA drive bays
  • 2200W Redundant Titanium Level Power Supplies
SYS-1029U-TN10RT

SYS-1029U-TN10RT

1U 1-Node Ultra

Intel with PCI-E 3.0

SYS-1029U-TN10RT

  • Dual 2nd Gen Intel® Xeon® Scalable processors
  • 24 DIMMs; Up to up to 6TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM; supports Intel® Optane™ DCPMM
  • 2 PCI-E 3.0 x16 slots (FH, 10.5" L)
  • 10 Hot-swap 2.5" NVMe drive bays
  • 1000W Redundant Titanium Level Power Supplies
SYS-2029BT-HNR

SYS-2029BT-HNR

2U 4-Node BigTwin®

Intel with PCI-E 3.0

SYS-2029BT-HNR

  • 4 hot-pluggable nodes in 2U; each node supports:
  • Dual 2nd Gen Intel® Xeon® Scalable processors
  • 24 DIMMs; up to 6TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM; Supports Intel® Optane™ DCPMM
  • 2 PCI-E 3.0 x16 (LP) slots
  • 6 Hot-swap 2.5" NVMe drive bays
  • 2200W Redundant Titanium Level Power Supplies

Certified Delta GPU RTX Servers for Weka GPUDirect Storage

AS -4124GO-NART AMD Delta GPU System

AS -4124GO-NART

4U AMD Delta GPU System

AS -4124GO-NART

  • Dual AMD EPYC™ 7003/7002 Series Processors
  • 32 DIMMs; up to 8TB Registered ECC DDR4 3200MHz SDRAM
  • 8 PCI-E 4.0 x16 via PCI-E switch;1 PCI-E 4.0 x16 LP and 1 PCI-E 4.0 x8 LP via CPUs
  • 6 Hot-swap 2.5" drive bays
  • 2200W (3+1) Redundant Platinum Level Power Supplies
SYS-420GP-TNAR Intel Delta GPU System

SYS-420GP-TNAR

4U Intel Delta GPU System

SYS-420GP-TNAR

  • Dual 3rd Gen Intel® Xeon® Scalable Processors
  • 32 DIMMs; Up to 8TB DRAM; Up to 8TB Intel® Optane™ Persistent Memory (up to 12TB with DRAM); 3200/2933/2666 ECC DDR4 LRDIMM/RDIMM;
  • 10 PCI-E 4.0 x16 LP slots
  • 6 Hot-swap 2.5" drive bays
  • 2200W (3+1) Redundant Platinum Level Power Supplies

認證網路適配器

AOC-CX766003N-SQ0

AOC-CX766003N-SQ0

AOC-653106A-HDAT

AOC-653106A-HDAT

AOC-653105A-HDAT

AOC-653105A-HDAT

AOC-MCX556A-ECAT

AOC-MCX556A-ECAT

AOC-MCX555A-ECAT

AOC-MCX555A-ECAT
