Intel® Xeon® 6700/6500 series processors with P-cores or 6700 series processors with E-cores, Single Socket LGA-4710 (Socket E2) supported, CPU TDP up to 350W
Up to 2TB ECC RDIMM DDR5-6400MT/s and up to 512GB MRDIMM DDR5-8000MT/s in 8 DIMM slots
6 PCIe 5.0 x8 via MCIO connectors (JNVME3–6 are enabled with the specific CPU** installed)
3 PCIe 5.0 x16 (SLOT6 is enabled with the specific CPU** installed), 3 PCIe 5.0 x8,M.2 Interface: 2 PCIe 5.0 x2 (Form Factor: 22110, M-Key)
Single Socket E2 (LGA-4710) supported, CPU TDP supports Up to 350W TDP
*BIOS 1.2 or above is required to support Intel® Xeon® 6700/6500-series processors with P-cores **Specific CPUs: Intel® Xeon® 6781P, 6761P, 6741P, 6731P, 6521P, 6511P
Core
Up to 144 E-cores or 86 P-cores
System Memory
Memory Capacity
8 DIMM slots
Up to 512GB ECC Registered MRDIMM (P-core only), DDR5-8000MT/s; Up to 2TB ECC Registered RDIMM, DDR5-6400MT/s
*Intel® Xeon® 6700/6500-series processors with P-cores is required to support MRDIMM
Memory Type
ECC DDR5 MRDIMM (P-core only), RDIMM
DIMM Sizes
16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB, 256GB
MRDIMM (P-core only): 32GB, 64GB
RDIMM: 16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB
RDIMM 3DS: 256GB
Memory Voltage
1.1V
Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-Board Devices
SATA
ASMediaASM1164 controller for 4 SATA ports
IPMI
ASPEED AST2600 BMC
Network Controllers
Dual LAN with 10GBase-T with Intel® X550
Input / Output
LAN
2 RJ45
1 RJ45
Serial Port
1 COM
Expansion Slots
PCIe
3 PCIe 5.0 x8,
3 PCIe 5.0 x16,
6 PCIe 5.0 x8 MCIO connector
(PCIe 5.0 SLOT6 and JNVME3-6 are enabled with the specific CPU** installed)
