Intel® Xeon® 6700/6500 series processors with P-cores or 6700 series processors with E-cores, Single Socket LGA-4710 (Socket E2) supported, CPU TDP up to 350W
Up to 512GB MRDIMM with speeds up to 8000 MT/s (1DPC) or 4TB of RDIMM(3DS) with speeds up to 6400 MT/s (1DPC) or 5200 MT/s (2DPC) in 16 DIMM slots
*BIOS 1.0 or above is required to support Intel® Xeon® 6700/6500-series processors with P-cores
Core Count
P-cores: Up to 86C/172T; Up to 336MB Cache
E-cores: Up to 144C/144T; Up to 108MB Cache
Note
Supports up to 350W TDP CPUs
System Memory
Memory
Slot Count: 16 DIMM Slots
Max Memory (1DPC): Up to 512GB 8000MT/s ECC DDR5 MRDIMM (P-core only)
Max Memory (1DPC): Up to 2TB 6400MT/s ECC DDR5 RDIMM/3DS RDIMM
Max Memory (2DPC): Up to 4TB 6400MT/s ECC DDR5 RDIMM/3DS RDIMM
DIMM Sizes
MRDIMM (P-core only):32GB, 64GB
RDIMM:16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB
3DS RDIMM:256GB
Memory Voltage
1.1V
Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-Board Devices
IPMI
ASPEED AST2600 BMC
Input / Output
LAN
1 RJ45 1 GbE Dedicated BMC LAN port(s)
USB
2 USB 3.0 port(s) (front)
Video
1 Mini DP port(s) (Front)
Serial
1 COM (Micro USB) port(s) (Front)
TPM
1 TPM header
Others
8 MCIO (PCIe 5.0 x8) port(s)
1 AIOM port(s)
Expansion Slots
PCI-Express (PCIe) Configuration
3 PCIe 5.0 x16 slots
1 PCIe 5.0 x16 AIOM slot
8 PCIe 5.0 x8 via MCIO Connector slots
(*Requires additional parts, please see the optional parts list for details. For more details on PCIe slot configuration options, please refer to the system callout images above.)
