Overview

Highlights

  • 2U 4-Node optimized for 1S with up to 16 DIMMs per node
  • Front or rear I/O options with modular design to increase flexibility and reduce cost
  • Front/Cold aisle serviceability with easy front node access

Innovations

  • Flexible and Cost-Optimized design for storage solutions
  • Resource Saving for Best Efficiency and TCO

Optimized for:

  • Virtualization
  • Cloud
  • Hosting & Content Delivery
  • Hyperscale / Hyperconverged
Product Features
2U rackmount server supporting 4 front-serviceable nodes with front or rear I/O

Form Factor

2U rackmount architecture supporting 4 front-serviceable nodes with front or rear I/O
16 DIMMs up to 4TB DDR5-4800

Memory

Up to 16 DIMM slots per node, up to 4TB DDR4-4800, support for Intel® Optane™ persistent memory
Supermicro GrandTwin Redundant Titanium Level Power Supplies

Power

2200W Redundant Titanium Level Power Supplies
Supermicro Open Industry Standard IPMI and Redfish APIs

Management

Open Industry Standard IPMI, Redfish APIs
Single 4th Gen Intel® Xeon® Scalable processor up to 350W TDP or AMD EPYC™ 9004 Series processor

Processors

Single 4th Gen Intel® Xeon® Scalable processor up to 350W TDP or AMD EPYC™ 9004 Series processor
Supermicro hot-swap NVMe/SATA

Drives

Up to 6x 2.5” hot-swap NVMe or SATA drives per node
Supermicro Integrated GrandTwin IO module supporting dual 10GbE or 25GbE LAN

Input/Output

Integrated GrandTwin I/O module supports dual 10GbE or 25GbE LAN
Supermicro Worldwide Global Services

Services

Worldwide Global Services
Models
