SAP HANA® Appliance and Tailored Data Center Integration (TDI)

Featuring the Latest Intel® Xeon® Scalable Processors

Supermicro has pre-validated, cost optimized, and bundled SAP S/4 HANA®, SAP BW/4HANA®, and HANA database into our best reference architecture for our customers either as appliance or Tailored Datacenter Integration (TDI) deployment. Our recent SAP HANA Certified Servers support up to 480 cores, up to 32 TB DDR5 memory and fastest all-flash NVMe or SSD storage options available for the SAP HANA® platform.

The SAP HANA Tailored Datacenter Integration (TDI) solution offers you more flexibility and freedom of choice to configure the SAP HANA hardware depending on your existing data center infrastructure. This option enables a reduction in acquisition and operational costs by allowing you to easily integrate new hardware with existing systems, software, and operational processes as long as they are listed on SAP’s Certified and Supported SAP HANA Hardware Directory.

Our SAP HANA Certified systems scale from 96GB to 32 TB DRAM:

BWoH, BW/4H, S/4H and DM
Supermicro ServerForm FactorMemory Sizing
SYS-681E-TR
SYS-681E-TR
(SPR, up to 480 cores)
6U MP SuperServer with 24x 2.5" Hot-swap NVMe/SAS3/SATA3Up to 32 TB
SYS-241E-TNRTTP
SYS-241E-TNRTTP
(SPR, up to 240 cores)
2U MP SuperServer with 24x 2.5" Hot-swap NVMe/SAS3/SATA3Up to 16 TB
SYS-221H-TNR
SYS-221H-TNR
(SPR, up to 120 cores)
2U Hyper with 8 hot-swap 2.5" NVMe/SAS/SATA baysUp to 8 TB
SYS-621C-TN12R
SYS-621C-TN12R
(SPR, up to 120 cores)
2U DP CloudDC with 12 hot-swap 3.5" NVMe/SAS/SATA baysUp to 4 TB
SYS-121C-TN10R
SYS-121C-TN10R
(SPR, up to 120 cores)
1U DP CloudDC with 10 hot-swap 2.5" NVMe/SAS/SATA baysUp to 4 TB
SYS-620U-TNR
SYS-620U-TNR
(ICX, up to 80 cores)
2U, dual socket, 12 x hot-swap 2.5" SSD (NVMe option)Up to 8 TB
SYS-120U-TNR
SYS-120U-TNR
(ICX, up to 80 cores)
2U, dual socket, 12 x hot-swap 2.5" SSD (NVMe option)Up to 8 TB
SYS-2029U-E1CRT with NVMe
SYS-2029U-E1CRT
(CLX, up to 56 cores)
2U, dual socket, 24 x hot-swap 2.5" SSD (NVMe option)Up to 6 TB
SYS-240P-TNRT
SYS-240P-TNRT
(CPX, up to 112 cores)
2U, quad socket, 24 x hot-swap 2.5" SSD (NVMe option)Up to 12 TB
SYS-2049U-TR4 with NVMe
SYS-2049U-TR4
(CLX, up to 112 cores)
2U, quad socket, 24 x hot-swap 2.5" SSD (NVMe option)Up to 12 TB
SYS-7089P-TR4T
SYS-7089P-TR4T
(CLX, up to 224 cores)
7U, octa socket, 16 x hot-swap 2.5" SSD (+ 16x internal NVMe)Up to 24 TB
