Intel® Xeon® 6700/6500-series processors with P-cores or E-cores, Single Socket LGA-4710 (Socket E2) supported, CPU TDP supports Up to 350W TDP
Up to 2TB DDR5 ECC RDIMM or 4TB RDIMM (3DS) with speeds of up to 6400MT/s (1DPC) or DDR5-5200MT/s (2DPC) or up to 512GB MRDIMM (1DPC) DDR5-8000MT/s in 16 DIMM slots
5x PCIe 5.0 x8 MCIO connectors for GPU Riser/NVMe/AIOM add on module
Single Socket E2 (LGA-4710) supported, CPU TDP supports Up to 350W TDP
*BIOS 1.0b or above is required to support Intel® Xeon® 6700/6500-series processors with P-cores
Core
Up to 144 E-cores or 86 P-cores
System Memory
Memory Capacity
16 DIMM slots
Up to 4TB 3DS ECC Registered 3DS, DDR5-6400MT/s; Up to 512GB ECC Registered MRDIMM (P-core only), DDR5-8000MT/s; Up to 2TB ECC Registered RDIMM, DDR5-6400MT/s
*Intel® Xeon® 6700/6500-series processors with P-cores is required to support MRDIMM
Memory Type
ECC DDR5 3DS (3DS), MRDIMM (P-core only), RDIMM Up to 512GB of memory with speeds of up to 8000 MT/s (MRDIMM 1DPC) or 2TB RDIMM (4TB with 3DS) of memory with speeds up to 6400 MT/s (1DPC) or 5200MT/s (2DPC)
DIMM Sizes
16GB, 24GB, 32GB, 48GB, 64GB, 96GB, 128GB, 256GB
3DS: 256GB
MRDIMM (P-core only): 32GB, 64GB
RDIMM: 16GB, 32GB, 48GB, 64GB, 96GB, 128GB
Memory Voltage
1.1V
Error Detection
Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset
System on Chip
IPMI
ASPEED AST2600 BMC
Network Controllers
Dual LAN with Intel® Ethernet Controller E810-XXVAM2, Two (2) 25GbE Ethernet ports from KR interface to BP
